The Apollo Mini Kit is best suited for simple applications where minimal directional control is required such as: roll-off trailers, boat lifts, wreckers, gates/doors, and winches. This compact system offers a palm sized, IP65 transmitter with either two, three, or four functions. The IP67 receiver is weather proof and available in AC or DC voltage. The 30-meter range is enough to keep operators at a safe distance but still highly productive..
Details
Specs
Documentation
Related Products
Model #: MINI20 | MINI30 | MINI40
- Functions: 2–4
- Frequency: FM 433 MHz
- Operating Range: 30 m (LOS)
- Ingress Protection: IP65
- Operating Temperature: 0°–70° C (32°–158° F)
- Rx Source Voltage: 12–24 VDC
- Protection: Short Protection
- Includes
- Transmitter: MINI20 or MINI30 or MINI40
- Receiver: AC or DC Power Receiver
+
–
Transmitter Specifications
Operating Range
30 M (LOS)
Frequency
FM 433 MHz
Response Time
100 ms
Output Power
< 10 mW
Operating Temperature
0°– +70° C (32°–158° F)
Antenna
Internal
Power Supply
1.5 V (2 AA Alkaline Batteries)
Ingress Protection
IP65
Material
Industrial ABS PC
Address Codes
256
Weight
95 g (Excluding Batteries)
Dimensions
124 × 48 × 25mm
+
–
Receiver Specifications
Frequency
FM 433 MHz
RF Sensitivity
-110 dBm
Antenna
Internal
Operating Temperature
−10°– +75° C (14°–167° F)
Antenna
Internal
Power Supply
12– 24VDC
Ingress Protection
IP65
Address Codes
256
Weight
270 g (Excluding Cable)
Power Consumption
<12W
Industries We Serve
Forestry | Utilities | Agriculture
The Apollo Mini Kit enhances control for tail lifts, utility gates and irrigation pumps.
Concrete | Construction | Municipal
The Apollo Mini Kit provides precise operation for concrete mixers, construction hoists and street sweeper doors.
Mining | Metals | Oil & Gas
The Apollo Mini Kit ensures reliable control for haul truck gates, metal press doors and oil rig access gates.
Defense & Aerospace
The Apollo Mini Kit delivers precise operation for military vehicle lifts and aerospace hangar doors.
